Grade:
Width:
Weight:
Abrasion:
Other Specs:

8
54 in
30.3 oz
100,000 DR
Face 100% Vinyl
Backing Hi-Loft2™ 100% Polyester
Weight 30.3 oz. per linear yd
Thickness 1.09 mm
Repeat H – 17.875″
V – 17.5″
Directional Yes
Railroaded No
Additional Attributes
Finish/Treatment Permablok3®
Silverguard®
Permablok3® Yes
Antibacterial Yes
Antimicrobial Yes
Bleach Cleanable Yes
Ratio: 75% Water / 25% Bleach Solution
Mildew Resistant Yes
Sulfide Stain Resistant Yes
Performance Characteristics
Abrasion Resistance (ASTM D4157) 100,000 double rubs
Tensile Strength (CFFA-17) Warp: 123.0 lbs.
Fill: 87.0 lbs.
Tear Strength (CFFA-16) Warp: 20.0 lbs.
Fill: 20.0 lbs.
Seam Slippage Warp: 12.0 lbs.
Fill: 9.2 lbs.
Colorfastness to Crocking (CFFA-7) Dry: Excellent
Wet: Excellent
UV Resistance (AATCC TM 16E) 1000 hours
Adhesion (CFFA-3) Warp: 3.3 lbs.
Fill: 3.3 lbs.
Cold Crack (CFFA-6) -20° F
Flammability*
CAL TB 117-E Passes
NFPA 260 Class 1
UFAC Class 1
Boston Fire Code Passes
Int’l Maritime Org., IMO A.652(16) 8.2 Passes
Int’l Maritime Org., IMO A.652(16) 8.3 Passes
FMVSS 302 Passes
Port Authority of NY/NJ Passes
Please refer to Detailed Cleaning Instructions above.
