Grade:
Width:
Weight:
Abrasion:
Other Specs:

8
54 in
14.9 oz
100,000 DR
Face 100% Vinyl
Backing 100% Polyester
Weight 37.0 oz. per linear yd
Thickness 1.28 mm
Width 54″
Directional No
Railroaded No
Additional Attributes
Finish/Treatment BeautyGard®
Oil Resistant
BeautyGard® Yes
Oil Resistant Yes
Antibacterial Yes
Antimicrobial Yes
Bleach Cleanable Yes
Ratio: 90% Water / 10% Bleach Solution
Mildew Resistant Yes
Sulfide Stain Resistant Yes
Performance Characteristics
Abrasion Resistance (ASTM D4157) 1,500,000 double rubs
Tensile Strength (191A-5100) Warp: 65.0 lbs.
Fill: 60.0 lbs.
Tear Strength (191A-5136) Warp: 14.0 lbs.
Fill: 12.0 lbs.
Seam Slippage Warp: 25.0 lbs.
Fill: 20.0 lbs.
Colorfastness to Crocking (191A-5651) Dry: Good
Wet: Good
UV Resistance (SAE J1885) 225.6 hours
Adhesion (CS-273-65) Warp: 3.0 lbs.
Fill: 3.0 lbs.
Blocking (191A-5872) 3
Cold Crack (191A-5874) -20° F
Flex (CS-273-65) 15,000 cycles
Flammability*
CAL TB 117-E Passes
NFPA 260 Class 1
UFAC Class 1
Federal Aviation Specification Passes
Federal Specification Passes
FMVSS 302 Passes
