Grade:
Width:
Weight:
Thickness:
Abrasion:
Other Specs:

7
54 in
33 oz
1 mm
30,000 DR
Face 96% Vinyl, 4% Rayon
Backing 50% Cotton,
50% Polyester
Directional Yes
Railroaded No
Additional Attributes
Finish/Treatment Resilience FSR
Performance Characteristics
Abrasion Resistance (ASTM D4157)
Tensile Strength (CFFA-17) Warp: 98.0 lbs.
Fill: 81.0 lbs.
Tear Strength (FTM 5136) Warp: 16.2 lbs.
Fill: 23.1 lbs.
UV Resistance (CFFA-4) 40 hours
Cold Crack (CFFA-6) -10° F
Flammability*
CAL TB 117-E Passes
NFPA 260 Class 1
UFAC Class 1
BIFMA CS-191-53, Sec. 3 Passes
BIFMA Upholstery, Sec. 4 Passes
Int’l Maritime Org., IMO A.652(16) 8.2 Passes
FMVSS 302 Passes
